Figure B-5--Texture and sedimentary structures in Misener Sandstone in TXO Sullivan No. H-4, 34-26N-7W.

1. 6048 ft--Medium-grained sandstone with abundant matrix, burrows, and bioturbation.

2. 6055 ft--Black shale bed in sharp contact with medium-grained sandstone.

3. 6056 ft--Large chert nodule at the base of the Misener.
