Figure 22--Bridging illite (IL), which appears to consist of very thin membrane covering most of framework grains and authigenic calcite (Ca) and quartz (OV). Some illite is whiskery. Sotong 5G-5.1, 2175.0 m msl. SEM photograph. Scale bar = 3 µm.
