Figure 5-3. MICP plots, plots of pore-throat size distribution, and photomicrographs of three shale types.

A. Shale type 2, seal for pay sections: Oil: 860-1175 ft Gas: 1000-1355 ft.

B. Shale type 3, seal for pay sections: Oil: 935-1235 ft Gas: 1125-1480 ft.

C. Shale type 4, seal for pay sections: Oil: 715-900 ft Gas: 885-1115 ft.
